Contec is pleased to introduce a new line of industrial performance servers for the security and defense industry. This unique family of high performance systems share the same proprietary Contec motherboard to provide a truly scalable infrastructure. Customers can ramp up system performance and functionality as needed without the need for additional testing. The industrial performance series offers an 8 to 10 year life cycle with provisions for extending when necessary.
Scalable Common Platform
Common platform provides scalable performance, reduced parts and inventory, shortened lead times and reduced testing requirements.
Long Life Cycle
Leverages Intel® long life components to provide 8+ years of consistent product availability.
Purpose-Built
Long life, scalable storage servers designed for compute-intensive security and defense applications in demanding environments.
GPU Support
Designed to support actively cooled single and dual slot width GPU options.
Security
Security capabilities prevent unauthorized system access or tampering of server settings.
Branding
Custom branding options available.
Product Specifications
System Description | 2U Rack Mount | |
Processor | (2) LGA3647-0 (Socket P) processor sockets. Compatible with 1 or 2 of any supported CPU. | |
Memory | 16 total DIMM slots 8 DIMM slots across 6 memory channels per processor 1 DIMM slot per memory channel on 4 channels 2 DIMM slots per memory channel on 2 channels Supported memory: Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM) Memory data transfer rate up to 2666 MT/s (processor SKU dependent) DDR4 standard voltage of 1.2 V |
|
Chipset | Intel® C624 Chipset | |
Local Area Network (LAN) | Dual port RJ45 10 GbE on board Optional Dual port RJ45 10 GbE riser |
|
Expansion Slots | (1) PCIe* 3.0 x16 slot (x16 electrical)
handled by CPU1via riser (1) Dual port RJ45 10 GbE via riser |
|
Video | Integrated 2D video controller 16 MB of DDR4 video memory |
|
RAID | Embedded SATA software RAID Intel® RSTe 5.0 Intel® Embedded Server RAID Technology 2 1.60 with optional RAID 5 key support |
|
Server Management | Integrated baseboard management controller, IPMI 2.0 compliant Support for Intel® Server Management software Dedicated onboard RJ45 management port Advanced server management via Intel® RMM4 Lite (accessory option) |
|
Security | Password protection Front panel lockout Trusted Platform Module (TPM 2.0) Intel® Trusted Execution Technology (Intel® TXT) |
|
GPU Support | Supports actively cooled single GPU in both single and dual processor configurations. | |
Storage | (2) Internal M.2 connectors – SATA / PCIe* 2280 form factor (10) x SATA 6 Gbps 2.5" hot-swap HDD/SSD bays, or (8) x SAS 2.5" hot-swap HDD/SSD bays |
|
External Connectors | (2) Rear Panel USB 2.0 ports (2) Rear Panel USB 3.0 ports (1) DB-15 external connector (1) Front Panel USB 3.0 ports |
|
Power Supply | 1200W 1U 1+1 Redundant PSU | |
Dimensions | - | |
Operating Temp | 5 to 40 °C | |
Operating Humidity (Max) | 85% (Non-Condensing) | |
Operating Altitude (Max) | 2,000 Meters | |
Regulatory | Regulatory | Standard met for Compliance |
EU Directive 2014/35/EU | IEC62368-1 | |
EU Directive 2004/108/EC | EN55032:2015 + AC:2016-07 Class B, EN55035:2010 + A1:2005, EN61000-3-2:2014, EN61000-3-3:2013 | |
North American Safety | CSA/UL 62368-1 via CSA Mark | |
North American EMI | FCC 47 CFR part 15 Subpart B, ICES-003 Issue 6:2016 | |
Life Cycle | 8+ years from date of introduction. Includes managed Bill of Materials with advanced notification of change. |
Don’t see exactly what you’re looking for? Contec has you covered!
We offer a wide range of custom engineering and design services:
Other services include:
Contact us today to speak with a specialist.
